Simple Wigglegram
focusing on the tree in the middle
This post is about the art and technology of my 3D wigglegrams, but first a bit of context about the location seen above.
This wigglegram was taken during my first visit to Kyoto's Shugakuin Imperial Villa (修学院離宮) two years ago, a photographically-fruitful outing first posted about here, and most recently revisited a month ago here.
During the tour of the grounds, at one point you descend stone steps set in the side of a mountain....
Nikon D4 + Nikkor 50mm f/1.4 — 1/125 sec, f/1.4, ISO 160 — map & image data — nearby photos
Stone Steps
There's a waterfall and a small stream... it's all quite picturesque.
Nikon D4 + Nikkor 24mm f/1.4 — 1/160 sec, f/1.4, ISO 100 — map & image data — nearby photos
Wider View
As I described on that first post about the outing, the tour moves along briskly, so despite the wonderfully photogenic scenes, the tour is not amenable to careful or leisurely photography.
So it was with haste that I spent just over one second to fire off a burst of 14 frames for this new “wigglegram” thing. I had published my first wigglegram just a week and a half prior.
It's been just over two years since I took the photos for this wigglegram, and though I haven't gotten much better at taking the raw frames, over time I have gotten much better at preparing them for display.
“Preparing them for display” means aligning them up to account for camera shake while moving the camera (and my body) from one side to another during the shutter burst that might last one or two seconds. It turns out that I'm pretty bad at keeping the camera level, so the need to align them well is pressing.
To show just how bad the original frames can be, here they are. (For the wigglegrams on this page, I'm using every other frame from the initial 14-frame burst, so these wigglegrams are seven frames long).
写真の上をマウスで左右にゆっくり動かすといろいろな撮影効果を楽しむことができます。
Original (Unaligned) Frames
showing my unsteady movements
I'm pretty good at holding the camera steady for a long exposure (such as seen here and here, for example), but clearly not good at holding the camera steady while moving. The images need to be aligned individually to form a unified whole.
Alignment consists of adjusting rotation and skew:
Adjusting the angle of each image so that what should be vertical is indeed vertical. As an example, the seven shots in the wigglegrams on this page were adjusted by 1.23°, 1.36°, 0.7°, 0.8°, 1.27°, 3.24°, and 3.95° respectively.
Crop each image to restore a consistent framing of the scene across all images.
Further crop each image to the maximum intersection of what remains of all the images, so that each image has the exact same pixel dimensions.
This is neither easy nor fun to do by hand in Lightroom, and this was a severely-limiting factor in my early wigglegram production.
I knew there must be some way to automate the alignment, but I'm no good at pixel-level programming. Thankfully, the kind folks behind the Hugin Panorama sticher included image-stacking features, and I was able to build a system that automated the alignment.
Results were.... spotty. Sometimes they were fantastic, and sometimes they were like this:
写真の上をマウスで左右にゆっくり動かすといろいろな撮影効果を楽しむことができます。
Auto-Aligned With Hugin Tools
(ところで、この実記の一番上のウイグルグラムが私が作った物です。)
It's much better than the originals, but it still leaves a lot to be desired. Sometimes it would even lend a kind of Salvador Dalíesque morph to various parts of various images. It was a step in the right direction, but I needed a better approach.
Finally, a few months ago I started writing a Lightroom plugin to align images using user-provided hints and guidance.
In Prograss
my plugin while creating the wigglegram that lead this post
At first I thought that aligning the images would be merely a technical undertaking, but it turns out that there's also an artistic component to choosing the alignment.
It may feel completely counter-intuitive, but you can take the same set of original and build wigglegrams with completely different focus points. For example, in the one at the top of this post, the focus point is the tree (referenced in the dialog above as “anchor point 3”), but here's one where it's the waterfall in the background...
写真の上をマウスで左右にゆっくり動かすといろいろな撮影効果を楽しむことができます。
From the Same Images
different feel
Like all the wigglegrams on this post, they're both built from the same original seven frames, so what's the difference? In the wigglegram at the top of this post, each frame is cropped so that a small orange leaf stuck to the middle of the main tree trunk is in the exact same location within each frame. That little orange leaf doesn't move from frame to frame; everything else does. This has the effect of the view rotating about the tree as you move.
In the wigglegram immediately above, the crop for each image is crafted so that the rock at the right side of the top of the waterfall doesn't move from frame to frame; everything else does. Here, everything seems to rotate about the background.
How can these completely-different sensations be built from the same originals? Doesn't it matter where the camera was pointing while the rapid-fire burst was being taken?
The key is to realize that when you focus on something with your eye (the tree or the waterfall or whatever), your perspective doesn't change. What changes is what you choose to keep unmoving in the center of your view.
Your perspective does change as you move your head to the side, just as the camera's perspective changes as it moves to the side. Once that perspective change is captured in the frames taken by the camera, when processing later you can use creative cropping to keep whatever you want “centered” and unmoving. In the examples above, the tree and the background, respectively, were kept unmoving from frame to frame, giving the feeling that that's what we were focused on while moving.
As a further example, here's a set of croppings where a yellow leaf in the near foreground was kept consistent across the frames:
写真の上をマウスで左右にゆっくり動かすといろいろな撮影効果を楽しむことができます。
Rotating About the Front
a small yellow leaf in the foreground is fixed across the whole
This one is much less satisfying than the others, for two reasons.
One of the reasons brings us back to the question "Doesn't it matter where the camera was pointing while the rapid-fire burst was being taken?" Where the camera points for each frame determines what part of the scene is available to each frame, which in turn has a direct impact on what parts of the scene are available to all frames of the unified whole. After each frame is aligned so that whatever we want to be unmoving across frames is unmoving, we have to set the crop dimensions for the unified whole such that it's contained within every (likely rotated and moved) individual frame.
If the camera was physically kept pointing at the same thing while it was swept from one side to the other — say, kept pointing exactly at the small orange leaf in the center of the tree trunk — and the camera was kept perfectly level, you'd not have to adjust anything, and you'd keep 100% of your pixels. But in the real world in my shaky hands, the best I can hope for is that the camera is kept generally in the right direction. In the case of this wigglegram, I did try to keep that leaf in the center, so after adjusting the frames I ended up keeping (not have to crop away) a not-too-bad 67% of the pixels.
But with “Rotating About the Front” just above, where the physical camera aim doesn't match the aim we're crafting, I had to crop away all but 20% of the pixels.
So, the tighter crop destroys the big sense that I was hoping to capture, making the result less satisfying.
(A further side effect of small crops from across the various frames is that you can get some pretty wild effects due to lens distortions, which tend to exaggerate toward the edge of the frame. Taking a small crop that runs from the middle of the first frame to the edge of the last frame can see a square morph into a squished rectangle, or vice versa.)
The other reason it's not satisfying is that the subject matter doesn't lend itself to rotation about the foreground. It just feels better rotating about the tree, or the background.
But you don't even have to rotate.
I realized this weekend that once you've adjusted everything so that whatever item you picked is unmoving from frame to frame, you can then go ahead and let it shift slightly across the view from frame to frame, to give a panning feel. For example:
写真の上をマウスで左右にゆっくり動かすといろいろな撮影効果を楽しむことができます。
Panning
This is a completely different feel. Here, I set the waterfall rock as the unmoving part, but then had it move across 20% of the field of view between the first and last frame. This gives the effect of rotating about an infinitely-distant point: a pan.
Frankly, it's not very appealing here, but I can imagine cases where it'd be useful.
More importantly, the technique can be used to fine-tune the rotation point by giving the impression that the rotation point is in front or behind whatever point you'd made fixed. For example, in this wigglegram of three ladies posing for the camera, I set the fixed point at the shoes of the lady in the middle. But imagine if they had been jumping (like this), then I'd have no spot on any of their bodies that stayed consistent from frame to frame around which to rotate. But now I can solve it by zeroing in on a rock or something nearby, then using a slight “pan” one way or the other to throw the perceived center of rotation exactly where I want it: in the middle of the three jumpers.
(That's a poorly-written paragraph about a complex idea... I'll have to just go shoot an example sometime, to make it clear.)
Anyway, as you can see from the many wigglegrams on this page, all derived from the same original photos, artistic feelings play an important role in deciding how to present them. I lead the post with the presentation I liked best. YMMV.
